24V 10A AC/DC PSU Regulated Switching Power Supply S-250-24 250W High Quality






International Buyers Please Note:
- Import duties, taxes and charges are not included in the itemprice or shipping charges. These charges are the buyer responsibility.
- Please check with your country customs office to determine what these additional costs will be prior to bidding/buying.

We will carefully test every item before shipment.

The quality is guaranteed!

140504-032

Features:

  • Convert AC input selected by switch ;
  • Over-voltage,over current,short circuit protection;
  • Heat from the cold;
  • 100% full load burn-in test;
  • Low-cost ,high reliability;

Model 　S-250-24
DC Output Voltage
　24V
Output voltage tolerance 　±1%
Rated output current 　10A
Output current range 　0-10A
Wave and noise 　150mVp-p
Inlet stability 　±0.5%
Load stability 　±0.5%
DC Output Power 　240W
Efficiency 　86%
Adjustable range for DC voltage 　±10%
AC input voltage range 90-132VAC/180-264V AC selected by switch 47-63Hz ;  254-370VDC
Input current 6A/115V AC        3.5A/230V AC
AC inrush current Cold start current 20A/115V     40A/230V
Leakage current ﹤3.5mA/240V AC
Overload protection 105%-150% Shut off current,automatically restore
Over voltage protection 115%-135% of output voltage
Temperature Coefficient ±0.03%/℃(0-50℃)
Setup/Rise/Hold up time 200ms,100ms,20ms
Vibration 10-500Hz,2G 10min/Cycle,X,Y,Z-axis each 60 minutes
Withstand voltage Input and output internal:1.5KVAC,input and enclosure:1.5KVAC,output and enclosure:0.5KVAC
Isolation resistance Input and output internal,input and enclosure,output and enclosure:500VDC/100MΩ
Working temperature and humidity -10℃-60℃,20%-90%RH
Store temperature and humidity -20℃-85℃,10%-95%RH
Weight 1150g
